Key Parameters
|
Cell |
POLY |
|
No. of cells |
36 (4*9) |
|
Rated Maximum Power (Pmax) |
150W~175W |
|
Junction Box |
IP67 |
|
Maximum System Voltage |
1000V DC |
|
Operating Temperature |
-40¡æ¡«+85¡æ |
|
Connectors |
MC4 |
|
Model |
OS-P36-150 |
OS-P36-165 |
OS-P36-175 |
|
Cell |
POLY |
POLY |
POLY |
|
Max Power |
150W |
165W |
175W |
|
Max Power Voltage |
18.0V |
18.9V |
18.9V |
|
Max Power Current |
8.33A |
8.73A |
9.26A |
|
Open Circuit Voltage |
21.4V |
21.66V |
22.49V |
|
Short Circuit Current |
8.83A |
9.14A |
9.81A |
|
Number of Cells |
36(4*9) |
36(4*9) |
36(4*9) |
|
Size of Cells (mm) |
156*156 |
156*156 |
156*156 |
|
Dimensions(mm) |
1480*670*35 |
1480*670*35 |
1480*670*35 |
|
Maximum system voltage |
1000VDC |
||
|
Junction Box Protection |
IP67 |
||
|
Cables |
4mm2 |
||
|
Connector |
MC4 |
||
|
Max wind load |
2400Pa |
||
|
Max snow load |
5400Pa |
||
|
Operating Temperature |
-40¡æ~+85¡æ |
||
|
Power Tolerance |
¡À3% |
||
