Key Parameters
| Cell | Mono |
| No. of cells | 60 |
| Rated Maximum Power (Pmax) | 250W/270W280W |
| Junction Box | IP67 |
| Maximum System Voltage | 1000V DC |
| Operating Temperature | -40¡æ¡«+85¡æ |
| Connectors | MC4 |
|
Model |
OS-M60-250 |
OS-M60-270 |
OS-M60-280 |
|
Cell |
MONO |
MONO |
MONO |
|
Max Power |
250W |
270W |
280W |
|
Max Power Voltage |
30.5V |
31.5V |
31.5V |
|
Max Power Current |
8.20A |
8.57A |
8.89A |
|
Open Circuit Voltage |
36V |
38.05V |
38.86V |
|
Short Circuit Current |
9.02A |
9.08A |
9.22A |
|
Number of Cells |
60(6*10) |
60(6*10) |
60(6*10£© |
|
Size of Cells (mm) |
156*156 |
156*156 |
156*156 |
|
Dimensions(mm) |
1640*992*35 |
1640*992*35 |
1640*992*35 |
|
Maximum system voltage |
1000VDC |
||
|
Junction Box Protection |
IP67 |
||
|
Cables |
4mm2 |
||
|
Connector |
MC4 |
||
|
Max wind load |
2400Pa |
||
|
Max snow load |
5400Pa |
||
|
Operating Temperature |
-40¡æ~+85¡æ |
||
|
Power Tolerance |
¡À3% |
||
